LangChain SDK

The Timbr LangChain SDK integrates natural language inputs with Timbr's ontology-driven semantic layer. Leveraging Timbr's robust ontology capabilities, the SDK integrates with Timbr data models and leverages semantic relationships and annotations, enabling users to query data in a business-friendly language.

It leverages Large Language Models (LLMs) to interpret user queries, generate Timbr SQL, and fetch query results from the database, enabling seamless interaction with any database connected to Timbr.

The SDK translates user questions into Timbr SQL, automatically aligning with the ontology's structure. This ensures context-aware results that reflect the underlying semantic relationships.

Requirements

To use this SDK, ensure you have the following:

Python Version: Python 3.9.13

Required Dependencies:

langchain==0.3.25
langchain_community==0.3.20
langgraph==0.3.20
pytimbr-api>=1.0.8
pydantic==2.10.4

Optional Dependencies (Depending on LLM):

langchain-anthropic==0.3.1
anthropic==0.42.0
langchain-openai==0.3.16
openai==1.77.0

Installation

Using pip

python -m pip install langchain-timbr

Install with selected LLM providers

One of: openai, anthropic, google, azure_openai, snowflake, databricks (or 'all')

python -m pip install 'langchain-timbr[<your selected providers, separated by comma w/o space>]'

Configuration

All chains, agents, and nodes support optional environment-based configuration. You can set the following environment variables to provide default values and have easy setup for the provided tools:

Timbr Connection Parameters

TIMBR_URL: Default Timbr server URL
TIMBR_TOKEN: Default Timbr authentication token
TIMBR_ONTOLOGY: Default ontology/knowledge graph name

When these environment variables are set, the corresponding parameters (url, token, ontology) become optional in all chain and agent constructors and will use the environment values as defaults.

LLM Configuration Parameters

LLM_TYPE: The type of LLM provider (One of langchain_timbr LlmTypes enum: 'openai-chat', 'anthropic-chat', 'chat-google-generative-ai', 'azure-openai-chat', 'snowflake-cortex', 'chat-databricks')
LLM_API_KEY: The API key for authenticating with the LLM provider
LLM_MODEL: The model name or deployment to use
LLM_TEMPERATURE: Temperature setting for the LLM
LLM_ADDITIONAL_PARAMS: Additional parameters as dict or JSON string

When LLM environment variables are set, the llm parameter becomes optional and will use the LlmWrapper with environment configuration.

Example environment setup:

# Timbr connection
export TIMBR_URL="https://your-timbr-app.com/"
export TIMBR_TOKEN="tk_XXXXXXXXXXXXXXXXXXXXXXXX"
export TIMBR_ONTOLOGY="timbr_knowledge_graph"

# LLM configuration
export LLM_TYPE="openai-chat"
export LLM_API_KEY="your-openai-api-key"
export LLM_MODEL="gpt-4o"
export LLM_TEMPERATURE="0.1"
export LLM_ADDITIONAL_PARAMS='{"max_tokens": 1000}'

Features

Multi-LLM Support: Integrates with OpenAI GPT, Anthropic Claude, Google Gemini, Databricks DBRX/llama, Snowflake Cortex and Timbr’s native LLM (Or any custom LLM using LangChain interface)
SQL Generation: Generate semantic SQL queries (ontology enriched queries).
Knowledge Graph Access: Interact with ontologies in natural language and retrieve context-aware answers.
Streamlined Querying: Combine natural language inputs with timbr using simple methods like run_llm_query.

LangChain interface

Timbr SQL Agent

Create a Timbr SQL agent that wraps the pipeline to identify the relevant concept and generate the SQL query over the ontology.

Parameters:

Parameter	Type / Default	Description
llm	LLM Default: None Optional	Language model instance (or a function taking a prompt string and returning an LLM's response). If None, uses `LlmWrapper` with environment variables.
url	str Default: None Optional	Timbr server URL. If None, uses the value from the `TIMBR_URL` environment variable.
token	str Default: None Optional	Timbr authentication token. If None, uses the value from the `TIMBR_TOKEN` environment variable.
ontology	str Default: None Optional	Name of the ontology/knowledge graph. If None, uses the value from the `TIMBR_ONTOLOGY` environment variable.
schema	str Default: None Optional	Name of the schema to query.
concept	str Default: None Optional	Name of a specific concept to query.
concepts_list	List[str] or str Default: None Optional	Collection of concepts to include (List of strings, or a string of concept names divided by comma). - If None, empty or '*', all available concepts are used. - If populated, only those concepts will be included in query generation. - If 'none' or 'null', no concepts will be used for the query.
views_list	List[str] or str Default: None Optional	Collection of views/cubes to include (List of strings, or a string of view/cube names divided by comma). - If None, empty or '*', all available views/cubes are used. - If populated, only those views/cubes will be included in query generation. - If 'none' or 'null', no views/cubes will be used for the query.
include_logic_concepts	bool Default: False Optional	Whether to include logic concepts (concepts without unique properties which only inherit from an upper level concept with filter logic) in the query. Note: This parameter has no effect when `concepts_list` is provided.
include_tags	List[str] or str Default: None Optional	Specific concept/property tag names to consider when generating the query. - If `None` or empty, no tags are used. - If a single string or list of strings is provided, only those tags (if they exist) will be attached to the prompt. - Use List of strings or a comma-separated string (e.g. `'tag1,tag2'`) to specify multiple tags. - Use `''` to include all* tags.
exclude_properties	List[str] or str Default: None Optional	Collection of properties to exclude from the query (List of strings, or a string of property names divided by comma. entity_id, entity_type & entity_label are excluded by default).
should_validate_sql	bool Default: True Optional	Whether to validate the SQL before executing it.
retries	int Default: 2 Optional	Number of retry attempts if the generated SQL is invalid.
max_limit	int Default: 100 Optional	Maximum number of rows to return.
retry_if_no_results	bool Default: False Optional	Whether to infer the result value from the SQL query. If the query won't return any rows, it will try to re-generate the SQL query then re-run it.
no_results_max_retries	int Default: 2 Optional	Number of retry attempts to infer the result value from the SQL query.
generate_answer	bool Default: False Optional	Whether to generate a natural language answer from the query results.
note	str Default: None Optional	Additional note to extend the LLM prompt.
db_is_case_sensitive	bool Default: False Optional	Whether the database is case sensitive.
graph_depth	int Default: 1 Optional	Maximum number of relationship hops to traverse from the source concept during schema exploration.
verify_ssl	bool Default: True Optional	Whether to verify SSL certificates.
is_jwt	bool Default: False Optional	Whether to use JWT authentication.
jwt_tenant_id	str Default: None Optional	Tenant ID for JWT authentication (if applicable).
conn_params	dict Default: None Optional	Extra Timbr connection parameters sent with every request (e.g., 'x-api-impersonate-user').

Create agent and use with AgentExecutor

from langchain_timbr import TimbrSqlAgent

agent = TimbrSqlAgent(
    # llm is optional if LLM environment variables are set
    llm=<llm>,  # optional:  uses LlmWrapper with env vars if not specified
    # url, token, ontology are optional if environment variables are set
    url="https://your-timbr-app.com/",  # optional:  uses TIMBR_URL if not specified
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",  # optional:  uses TIMBR_TOKEN if not specified
    ontology="timbr_knowledge_graph",  # optional:  uses TIMBR_ONTOLOGY/ONTOLOGY if not specified
    schema="dtimbr",               # optional
    concept="Sales",               # optional
    concepts_list=["Sales","Orders","Customers"],  # optional
    views_list=["sales_view"],     # optional
    note="Focus on US region",     # optional
    retries=2,                     # optional
    should_validate_sql=True       # optional
)

agent_executor = AgentExecutor.from_agent_and_tools(
    agent=agent,
    tools=[],
    verbose=True
)
result = agent_executor.invoke("What are the total sales for last month?")

rows = result["rows"]
sql = result["sql"]
concept = result["concept"]
schema = result["schema"]
error = result.get("error", None)

usage_metadata = result.get("usage_metadata", {})
determine_concept_usage = usage_metadata.get('determine_concept', {})
generate_sql_usage = usage_metadata.get('generate_sql', {})
# Each usage_metadata item contains:
# * 'approximate': Estimated token count calculated before invoking the LLM
# * 'input_tokens'/'output_tokens'/'total_tokens'/etc.: Actual token usage metrics returned by the LLM

Use create_timbr_sql_agent to get AgentExecutor instance and invoke directly

from langchain_timbr import create_timbr_sql_agent

agent_executor = create_timbr_sql_agent(
    llm=<llm>,                     # optional - if not provided, uses LlmWrapper with environment variables
    # url, token, ontology are optional if environment variables are set
    url="https://your-timbr-app.com/",  # optional:  uses TIMBR_URL if not specified
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",  # optional:  uses TIMBR_TOKEN if not specified
    ontology="timbr_knowledge_graph",  # optional:  uses TIMBR_ONTOLOGY/ONTOLOGY if not specified
    schema="dtimbr",               # optional
    concept="Sales",               # optional
    concepts_list=["Sales","Orders","Customers"],  # optional
    views_list=["sales_view"],     # optional
    note="Focus on US region",     # optional
)

result = agent_executor.invoke("What are the total sales for last month?")

rows = result["rows"]
sql = result["sql"]
concept = result["concept"]
schema = result["schema"]
error = result.get("error", None)

Identify Concept Chain

Returns the suggested concept to query based on the user question.

Parameters:

Parameter	Type / Default	Description
llm	LLM Default: None Optional	Language model instance (or a function taking a prompt string and returning an LLM's response). If None, uses `LlmWrapper` with environment variables.
url	str Default: None Optional	Timbr server URL. If None, uses the value from the `TIMBR_URL` environment variable.
token	str Default: None Optional	Timbr authentication token. If None, uses the value from the `TIMBR_TOKEN` environment variable.
ontology	str Default: None Optional	Name of the ontology/knowledge graph. If None, uses the value from the `TIMBR_ONTOLOGY` environment variable.
concepts_list	List[str] or str Default: None Optional	Collection of concepts to include (List of strings, or a string of concept names divided by comma). - If None, empty or '*', all available concepts are used. - If populated, only those concepts will be included in query generation. - If 'none' or 'null', no concepts will be used for the query.
views_list	List[str] or str Default: None Optional	Collection of views/cubes to include (List of strings, or a string of view/cube names divided by comma). - If None, empty or '*', all available views/cubes are used. - If populated, only those views/cubes will be included in query generation. - If 'none' or 'null', no views/cubes will be used for the query.
include_logic_concepts	bool Default: False Optional	Whether to include logic concepts (concepts without unique properties which only inherit from an upper level concept with filter logic) in the query. Note: This parameter has no effect when `concepts_list` is provided.
include_tags	List[str] or str Default: None Optional	Specific concept/property tag names to consider when generating the query. - If `None` or empty, no tags are used. - If a single string or list of strings is provided, only those tags (if they exist) will be attached to the prompt. - Use List of strings or a comma-separated string (e.g. `'tag1,tag2'`) to specify multiple tags. - Use `''` to include all* tags.
should_validate_sql	bool Default: True Optional	Whether to validate the identified concept before returning it.
retries	int Default: 2 Optional	Number of retry attempts if the identified concept is invalid.
note	str Default: None Optional	Additional note to extend the LLM prompt.
verify_ssl	bool Default: True Optional	Whether to verify SSL certificates.
is_jwt	bool Default: False Optional	Whether to use JWT authentication.
jwt_tenant_id	str Default: None Optional	Tenant ID for JWT authentication (if applicable).
conn_params	dict Default: None Optional	Extra Timbr connection parameters sent with every request (e.g., 'x-api-impersonate-user').

from langchain_timbr import IdentifyTimbrConceptChain

identify_timbr_concept_chain = IdentifyTimbrConceptChain(
    # llm is optional if LLM environment variables are set
    llm=<llm>,  # optional:  uses LlmWrapper with env vars if not specified
    # url, token, ontology are optional if environment variables are set
    url="https://your-timbr-app.com/",  # optional:  uses TIMBR_URL if not specified
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",  # optional:  uses TIMBR_TOKEN if not specified
    ontology="timbr_knowledge_graph",  # optional:  uses TIMBR_ONTOLOGY/ONTOLOGY if not specified
    concepts_list=["Sales","Orders"],  # optional
    views_list=["sales_view"],         # optional
    note="Focus on last month's data"  # optional
)

result = identify_timbr_concept_chain.invoke({ "prompt": "What are the total sales for last month?" })
concept = result["concept"]
schema = result["schema"]

usage_metadata = result.get("identify_concept_usage_metadata", {})
determine_concept_usage = usage_metadata.get('determine_concept', {})
# Each usage_metadata item contains:
# * 'approximate': Estimated token count calculated before invoking the LLM
# * 'input_tokens'/'output_tokens'/'total_tokens'/etc.: Actual token usage metrics returned by the LLM

Generate SQL Chain

Returns the suggested SQL based on the user question.

Parameters:

Parameter	Type / Default	Description
llm	LLM Default: None Optional	Language model instance (or a function taking a prompt string and returning an LLM's response). If None, uses `LlmWrapper` with environment variables.
url	str Default: None Optional	Timbr server URL. If None, uses the value from the `TIMBR_URL` environment variable.
token	str Default: None Optional	Timbr authentication token. If None, uses the value from the `TIMBR_TOKEN` environment variable.
ontology	str Default: None Optional	Name of the ontology/knowledge graph. If None, uses the value from the `TIMBR_ONTOLOGY` environment variable.
schema	str Default: None Optional	Name of the schema to query.
concept	str Default: None Optional	Name of a specific concept to query.
concepts_list	List[str] or str Default: None Optional	Collection of concepts to include (List of strings, or a string of concept names divided by comma). - If None, empty or '*', all available concepts are used. - If populated, only those concepts will be included in query generation. - If 'none' or 'null', no concepts will be used for the query.
views_list	List[str] or str Default: None Optional	Collection of views/cubes to include (List of strings, or a string of view/cube names divided by comma). - If None, empty or '*', all available views/cubes are used. - If populated, only those views/cubes will be included in query generation. - If 'none' or 'null', no views/cubes will be used for the query.
include_logic_concepts	bool Default: False Optional	Whether to include logic concepts (concepts without unique properties which only inherit from an upper level concept with filter logic) in the query. Note: This parameter has no effect when `concepts_list` is provided.
include_tags	List[str] or str Default: None Optional	Specific concept/property tag names to consider when generating the query. - If `None` or empty, no tags are used. - If a single string or list of strings is provided, only those tags (if they exist) will be attached to the prompt. - Use List of strings or a comma-separated string (e.g. `'tag1,tag2'`) to specify multiple tags. - Use `''` to include all* tags.
exclude_properties	List[str] or str Default: None Optional	Collection of properties to exclude from the query (List of strings, or a string of property names divided by comma. entity_id, entity_type & entity_label are excluded by default).
should_validate_sql	bool Default: True Optional	Whether to validate the SQL before executing it.
retries	int Default: 2 Optional	Number of retry attempts if the generated SQL is invalid.
max_limit	int Default: 100 Optional	Maximum number of rows to return.
note	str Default: None Optional	Additional note to extend the LLM prompt.
db_is_case_sensitive	bool Default: False Optional	Whether the database is case sensitive.
graph_depth	int Default: 1 Optional	Maximum number of relationship hops to traverse from the source concept during schema exploration.
verify_ssl	bool Default: True Optional	Whether to verify SSL certificates.
is_jwt	bool Default: False Optional	Whether to use JWT authentication.
jwt_tenant_id	str Default: None Optional	Tenant ID for JWT authentication (if applicable).
conn_params	dict Default: None Optional	Extra Timbr connection parameters sent with every request (e.g., 'x-api-impersonate-user').

from langchain_timbr import GenerateTimbrSqlChain

generate_timbr_sql_chain = GenerateTimbrSqlChain(
    # llm is optional if LLM environment variables are set
    llm=<llm>,  # optional:  uses LlmWrapper with env vars if not specified
    # url, token, ontology are optional if environment variables are set
    url="https://your-timbr-app.com/",  # optional:  uses TIMBR_URL if not specified
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",  # optional:  uses TIMBR_TOKEN if not specified
    ontology="timbr_knowledge_graph",  # optional:  uses TIMBR_ONTOLOGY/ONTOLOGY if not specified
    schema="dtimbr",      # optional
    concept="Sales",      # optional
    concepts_list=["Sales","Orders"],  # optional
    views_list=["sales_view"],         # optional
    note="We only need sums"           # optional
)

result = generate_timbr_sql_chain.invoke({ "prompt": "What are the total sales for last month?" })
sql = result["sql"]
concept = result["concept"]
schema = result["schema"]

usage_metadata = result.get("generate_sql_usage_metadata", {})
determine_concept_usage = usage_metadata.get('determine_concept', {})
generate_sql_usage = usage_metadata.get('generate_sql', {})
# Each usage_metadata item contains:
# * 'approximate': Estimated token count calculated before invoking the LLM
# * 'input_tokens'/'output_tokens'/'total_tokens'/etc.: Actual token usage metrics returned by the LLM

Validate SQL Chain

Validates the timbr SQL and re-generate a new one if necessary based on the user question.

Parameters:

Parameter	Type / Default	Description
llm	LLM Default: None Optional	Language model instance (or a function taking a prompt string and returning an LLM's response). If None, uses `LlmWrapper` with environment variables.
url	str Default: None Optional	Timbr server URL. If None, uses the value from the `TIMBR_URL` environment variable.
token	str Default: None Optional	Timbr authentication token. If None, uses the value from the `TIMBR_TOKEN` environment variable.
ontology	str Default: None Optional	Name of the ontology/knowledge graph. If None, uses the value from the `TIMBR_ONTOLOGY` environment variable.
schema	str Default: None Optional	Name of the schema to query.
concept	str Default: None Optional	Name of a specific concept to query.
retries	int Default: 2 Optional	Number of retry attempts if the generated SQL is invalid.
concepts_list	List[str] or str Default: None Optional	Collection of concepts to include (List of strings, or a string of concept names divided by comma). - If None, empty or '*', all available concepts are used. - If populated, only those concepts will be included in query generation. - If 'none' or 'null', no concepts will be used for the query.
views_list	List[str] or str Default: None Optional	Collection of views/cubes to include (List of strings, or a string of view/cube names divided by comma). - If None, empty or '*', all available views/cubes are used. - If populated, only those views/cubes will be included in query generation. - If 'none' or 'null', no views/cubes will be used for the query.
include_logic_concepts	bool Default: False Optional	Whether to include logic concepts (concepts without unique properties which only inherit from an upper level concept with filter logic) in the query. Note: This parameter has no effect when `concepts_list` is provided.
include_tags	List[str] or str Default: None Optional	Specific concept/property tag names to consider when generating the query. - If `None` or empty, no tags are used. - If a single string or list of strings is provided, only those tags (if they exist) will be attached to the prompt. - Use List of strings or a comma-separated string (e.g. `'tag1,tag2'`) to specify multiple tags. - Use `''` to include all* tags.
exclude_properties	List[str] or str Default: None Optional	Collection of properties to exclude from the query (List of strings, or a string of property names divided by comma. entity_id, entity_type & entity_label are excluded by default).
max_limit	int Default: 100 Optional	Maximum number of rows to return.
note	str Default: None Optional	Additional note to extend the LLM prompt.
db_is_case_sensitive	bool Default: False Optional	Whether the database is case sensitive.
graph_depth	int Default: 1 Optional	Maximum number of relationship hops to traverse from the source concept during schema exploration.
verify_ssl	bool Default: True Optional	Whether to verify SSL certificates.
is_jwt	bool Default: False Optional	Whether to use JWT authentication.
jwt_tenant_id	str Default: None Optional	Tenant ID for JWT authentication (if applicable).
conn_params	dict Default: None Optional	Extra Timbr connection parameters sent with every request (e.g., 'x-api-impersonate-user').

from langchain_timbr import ValidateTimbrSqlChain

validate_timbr_sql_chain = ValidateTimbrSqlChain(
    llm=<llm>,  # optional:  uses LlmWrapper with env vars if not specified
    # url, token, ontology are optional if environment variables are set
    url="https://your-timbr-app.com/",  # optional:  uses TIMBR_URL if not specified
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",  # optional:  uses TIMBR_TOKEN if not specified
    ontology="timbr_knowledge_graph",  # optional:  uses TIMBR_ONTOLOGY/ONTOLOGY if not specified
    schema="dtimbr",               # optional
    concept="Sales",               # optional
    concepts_list=["Sales","Orders"],  # optional
    views_list=["sales_view"],         # optional
    note="We only need sums",     # optional
    retries=3
)

result = validate_timbr_sql_chain.invoke({
    "prompt": "What are the total sales for last month?",
    "sql": "SELECT SUM(amount) FROM sales WHERE date > current_date - INTERVAL '1 month'"
})

validated_sql = result["sql"]
is_sql_valid = result["is_sql_valid"]
error = result["error"]
concept = result["concept"]
schema = result["schema"]

usage_metadata = result.get("validate_sql_usage_metadata", {})
determine_concept_usage = usage_metadata.get('determine_concept', {})
generate_sql_usage = usage_metadata.get('generate_sql', {})
# Each usage_metadata item contains:
# * 'approximate': Estimated token count calculated before invoking the LLM
# * 'input_tokens'/'output_tokens'/'total_tokens'/etc.: Actual token usage metrics returned by the LLM

Execute Query Chain

Calls the Generate SQL Chain and executes the query in timbr. Returns the query results.

Parameters:

Parameter	Type / Default	Description
llm	LLM Default: None Optional	Language model instance (or a function taking a prompt string and returning an LLM's response). If None, uses `LlmWrapper` with environment variables.
url	str Default: None Optional	Timbr server URL. If None, uses the value from the `TIMBR_URL` environment variable.
token	str Default: None Optional	Timbr authentication token. If None, uses the value from the `TIMBR_TOKEN` environment variable.
ontology	str Default: None Optional	Name of the ontology/knowledge graph. If None, uses the value from the `TIMBR_ONTOLOGY` environment variable.
schema	str Default: None Optional	Name of the schema to query.
concept	str Default: None Optional	Name of a specific concept to query.
concepts_list	List[str] or str Default: None Optional	Collection of concepts to include (List of strings, or a string of concept names divided by comma). - If None, empty or '*', all available concepts are used. - If populated, only those concepts will be included in query generation. - If 'none' or 'null', no concepts will be used for the query.
views_list	List[str] or str Default: None Optional	Collection of views/cubes to include (List of strings, or a string of view/cube names divided by comma). - If None, empty or '*', all available views/cubes are used. - If populated, only those views/cubes will be included in query generation. - If 'none' or 'null', no views/cubes will be used for the query.
include_logic_concepts	bool Default: False Optional	Whether to include logic concepts (concepts without unique properties which only inherit from an upper level concept with filter logic) in the query. Note: This parameter has no effect when `concepts_list` is provided.
include_tags	List[str] or str Default: None Optional	Specific concept/property tag names to consider when generating the query. - If `None` or empty, no tags are used. - If a single string or list of strings is provided, only those tags (if they exist) will be attached to the prompt. - Use List of strings or a comma-separated string (e.g. `'tag1,tag2'`) to specify multiple tags. - Use `''` to include all* tags.
exclude_properties	List[str] or str Default: None Optional	Collection of properties to exclude from the query (List of strings, or a string of property names divided by comma. entity_id, entity_type & entity_label are excluded by default).
should_validate_sql	bool Default: True Optional	Whether to validate the SQL before executing it.
retries	int Default: 2 Optional	Number of retry attempts if the generated SQL is invalid.
max_limit	int Default: 100 Optional	Maximum number of rows to return.
retry_if_no_results	bool Default: False Optional	Whether to infer the result value from the SQL query. If the query won't return any rows, it will try to re-generate the SQL query then re-run it.
no_results_max_retries	int Default: 2 Optional	Number of retry attempts to infer the result value from the SQL query.
note	str Default: None Optional	Additional note to extend the LLM prompt.
db_is_case_sensitive	bool Default: False Optional	Whether the database is case sensitive.
graph_depth	int Default: 1 Optional	Maximum number of relationship hops to traverse from the source concept during schema exploration.
verify_ssl	bool Default: True Optional	Whether to verify SSL certificates.
is_jwt	bool Default: False Optional	Whether to use JWT authentication.
jwt_tenant_id	str Default: None Optional	Tenant ID for JWT authentication (if applicable).
conn_params	dict Default: None Optional	Extra Timbr connection parameters sent with every request (e.g., 'x-api-impersonate-user').

from langchain_timbr import ExecuteTimbrQueryChain

execute_timbr_query_chain = ExecuteTimbrQueryChain(
    llm=<llm>,  # optional:  uses LlmWrapper with env vars if not specified
    # url, token, ontology are optional if environment variables are set
    url="https://your-timbr-app.com/",  # optional:  uses TIMBR_URL if not specified
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",  # optional:  uses TIMBR_TOKEN if not specified
    ontology="timbr_knowledge_graph",  # optional:  uses TIMBR_ONTOLOGY/ONTOLOGY if not specified
    schema="dtimbr",              # optional
    concept="Sales",              # optional
    concepts_list=["Sales","Orders"],  # optional
    views_list=["sales_view"],         # optional
    note="We only need sums",     # optional
    retries=3,                    # optional
    should_validate_sql=True      # optional
)

result = execute_timbr_query_chain.invoke({ "prompt": "What are the total sales for last month?" })
rows = result["rows"]
sql = result["sql"]
concept = result["concept"]
schema = result["schema"]
error = result.get("error", None)

usage_metadata = result.get("execute_timbr_usage_metadata", {})
determine_concept_usage = usage_metadata.get('determine_concept', {})
generate_sql_usage = usage_metadata.get('generate_sql', {})
# Each usage_metadata item contains:
# * 'approximate': Estimated token count calculated before invoking the LLM
# * 'input_tokens'/'output_tokens'/'total_tokens'/etc.: Actual token usage metrics returned by the LLM

Generate Answer Chain

Generates answer based on the prompt and query results.

Parameters:

Parameter	Type / Default	Description
llm	LLM Default: None Optional	Language model instance (or a function taking a prompt string and returning an LLM's response). If None, uses `LlmWrapper` with environment variables.
url	str Default: None Optional	Timbr server URL. If None, uses the value from the `TIMBR_URL` environment variable.
token	str Default: None Optional	Timbr authentication token. If None, uses the value from the `TIMBR_TOKEN` environment variable.
verify_ssl	bool Default: True Optional	Whether to verify SSL certificates.
is_jwt	bool Default: False Optional	Whether to use JWT authentication.
jwt_tenant_id	str Default: None Optional	Tenant ID for JWT authentication (if applicable).
conn_params	dict Default: None Optional	Extra Timbr connection parameters sent with every request (e.g., 'x-api-impersonate-user').

from langchain_timbr import GenerateAnswerChain

generate_answer_chain = GenerateAnswerChain(
    llm=<llm>,  # optional:  uses LlmWrapper with env vars if not specified
    # url, token are optional if environment variables are set
    url="https://your-timbr-app.com/",  # optional:  uses TIMBR_URL if not specified
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",  # optional:  uses TIMBR_TOKEN if not specified
)

answer_result = generate_answer_chain.invoke({
    "prompt": "What are the total sales for last month?",
    "rows": [{"total_sales": 1250000}],
    "sql": "SELECT COUNT(1) AS `total_sales` FROM `dtimbr`.`order`",
})

answer = answer_result["answer"]

usage_metadata = result.get("generate_answer_usage_metadata", {})
answer_question_usage = usage_metadata.get('answer_question', {})
# Each usage_metadata item contains:
# * 'approximate': Estimated token count calculated before invoking the LLM
# * 'input_tokens'/'output_tokens'/'total_tokens'/etc.: Actual token usage metrics returned by the LLM

Quick Start using Timbr API

1. Initialize LLM instance

# Using env variables configurations
from langchain_timbr import LlmWrapper
llm = LlmWrapper()

# Using OpenAI provider:
from langchain_openai import ChatOpenAI
llm = ChatOpenAI(
    openai_api_key="<api_key>",
    model_name="gpt-4o", # or any other preferred model
)

# Using Anthropic provider:
from langchain_anthropic import ChatAnthropic
llm = Claude(
    anthropic_api_key="<api_key>",
    model="claude-sonnet-4-20250514", # or any other preferred model
)

# Or any other LLM provider as your wish as ChatGoogleGenerativeAI, ChatSnowflakeCortex, AzureChatOpenAI, etc.

2. Initialize timbr agent executor

from langchain_timbr import create_timbr_sql_agent

agent_executor = create_timbr_sql_agent(
    llm=llm,
    url="https://your-timbr-app.com/",
    token="tk_XXXXXXXXXXXXXXXXXXXXXXXX",
    ontology="timbr_knowledge_graph",
    schema="dtimbr",               # optional
    concept="Sales",               # optional
    concepts_list=["Sales","Orders","Customers"],  # optional
    views_list=["sales_view"],     # optional
    note="Focus on US region",     # optional
    generate_answer=False,         # optional
)

3. Invoke agent with user question & fetch results

result = agent_executor.invoke("What are the total sales for last month?")

answer = result["answer"] # Relevant when generate_answer is True
rows = result["rows"]
sql = result["sql"]
schema = result["schema"]
concept = result["concept"]
user_metadata = result["user_metadata"] # Token usage metadata - estimated & from llm response
error = result.get("error", None)

Examples

Explore the examples/ directory for detailed use cases, including:

Streamlit Integration: Build a user-friendly app to query Timbr interactively.
LangChain Chains: Use GenerateTimbrSqlChain, ExecuteTimbrQueryChain & more, for more granular control.
Custom Agents: Create custom agents with LangChain’s AgentExecutor to handle complex workflows.

Timbr Methods Overview

`get_ontologies`

Fetch a list of available knowledge graphs in the Timbr environment.

ontologies_list = llm_connector.get_ontologies()

`set_ontology`

Set or switch the ontology for subsequent operations.

llm_connector.set_ontology("<ontology_name>")

`determine_concept`

Use the LLM to determine the appropriate concept and schema for a query.

concept_name, schema_name = llm_connector.determine_concept("Show me sales by region.")

`generate_sql`

Generate Timbr SQL for a user query.

sql_query = llm_connector.generate_sql("What is the revenue by product category?", concept_name="sales_data")

`validate_sql`

Validates Timbr SQL.

is_sql_valid, error = llm_connector.validate_sql("What is the revenue by product category?", sql_query="SELECT SUM(revenue) FROM sales GROUP BY product_category")

`run_timbr_query`

Run a Timbr SQL query and fetch results.

results = llm_connector.run_timbr_query("SELECT * FROM sales_data")

`run_llm_query`

Combine SQL generation and execution in a single step.

response = llm_connector.run_llm_query("What are the top 5 products by sales?")

LangChain

Requirements​

Installation​

Using pip​

Install with selected LLM providers​

One of: openai, anthropic, google, azure_openai, snowflake, databricks (or 'all')​

Configuration​

Timbr Connection Parameters​

LLM Configuration Parameters​

Features​

LangChain interface​

Timbr SQL Agent​

Create agent and use with AgentExecutor​

Use create_timbr_sql_agent to get AgentExecutor instance and invoke directly​

Identify Concept Chain​

Generate SQL Chain​

Validate SQL Chain​

Execute Query Chain​

Generate Answer Chain​

Quick Start using Timbr API​

1. Initialize LLM instance​

2. Initialize timbr agent executor​

3. Invoke agent with user question & fetch results​

Examples​

Timbr Methods Overview​

get_ontologies​

set_ontology​

determine_concept​

generate_sql​

validate_sql​

run_timbr_query​

run_llm_query​

Requirements

Installation

Using pip

Install with selected LLM providers

One of: openai, anthropic, google, azure_openai, snowflake, databricks (or 'all')

Configuration

Timbr Connection Parameters

LLM Configuration Parameters

Features

LangChain interface

Timbr SQL Agent

Create agent and use with AgentExecutor

Use create_timbr_sql_agent to get AgentExecutor instance and invoke directly

Identify Concept Chain

Generate SQL Chain

Validate SQL Chain

Execute Query Chain

Generate Answer Chain

Quick Start using Timbr API

1. Initialize LLM instance

2. Initialize timbr agent executor

3. Invoke agent with user question & fetch results

Examples

Timbr Methods Overview

`get_ontologies`

`set_ontology`

`determine_concept`

`generate_sql`

`validate_sql`

`run_timbr_query`

`run_llm_query`
